Open-Source Vehicle Control Compatibility

The STM32H743 platform is compatible with leading open-source vehicle control firmware such as INAV, Betaflight, and ArduPilot, and may support additional STM32H743-based firmware stacks, making it a flexible foundation for drones, rovers, and other autonomous vehicles.

• MCU STM32H743VIT6, 480MHz, 2MB Flash
• IMU1 ICM42605
• IMU2 MPU-6000
• Magnetometer HMC5883L
• Barometer DPS310
• OSD MAX7456
• 12x PWM outputs
• 7x UARTs
• 1x CAN
• 2x I2C
• 1x SPI
• 1x Beeper
• 1x WS2811 Led Strip
• 4x ADC inputs
• Dual switchable Analog Video input
• 5-28V DC IN (2 to 6 LiPo)
• 220A Current and Voltage monitor
• BEC 5V 8A
